5.0-inch Intelligent Liquid Crystal Module

The EzUI050 smart LCD screen has a 5.0-inch (diagonal) color TFT display, 800 × 480 dot matrix, 16-bit color depth; the module has 128M bytes of resource memory inside. The module needs 5V DC power supply, and the external interface of the module is serial UART (TTL level) interface. The interface is simple and easy to operate. It can be easily and simply interfaced with various MCUs. The biggest feature of the EzUI series modules is that they are easy to use and feature-rich, and users can use them easily. Users can use the interface development tool software (EzUITool) to design, edit, control, and respond to the human-machine interface. Copy the resource files generated by the tool software into the EzUI series module to achieve the required human-computer interaction interface. Designed without the need for programming control of the microcontroller or other controller. To meet the needs of users with special requirements, the EzUI series modules retain most of the display control commands (similar to the MzTH series modules), so that users can more freely control the module display. The EzUI series modules integrate a self-contained GUI based on a TFT display and a touch screen (optional for touch screen)


The system, combined with the interface development tool software (EzUITool), can achieve the goal of user interface design without code.




1 UART serial interface (TTL level, optional RS232 level interface) mode, support 9600~115200bps;

2 The standard version of the module has a built-in 128M bytes of resource memory;

3 resistance touch screen options;

4 Support module USB interface debugging (module onboard USB port can be debugged in the computer virtual serial port);

5 Optional RTC real-time clock module;

6 module comes with 6×10, 8×16, 10×20, 16×32 dot ASCII code western font library;

7 Support basic drawing instructions (painting points, lines, rectangles, circles, string display, bitmap display, etc.);

8 resource memory support GBK2312 second-level Chinese character library, BIG5 font library, BMP bitmap, ASCII western font library, etc.;

9 Support area button (original touch area) control, multiple attribute configuration, control message response configurable;

10 Support bitmap button (in-place touch button) control, multiple attribute configuration, control message response configurable;

11 Support numerical control (integer, floating point number), multiple attribute configuration, support numerical input;

12 Support string control (both Chinese and English), multiple attribute configuration, support Chinese and English string input;

13 Support drop-down selection (original pop-up drop-down box) control, control message response can be configured;

14 Support waveform control, allowing up to four waveform lines in the same ID number control;

15 support progress bar control, control message response can be configured;

16 support bitmap animation control, control message response configurable;

17 Support time display and date display control.
