With the wide application of human-machine interface, the display content is gradually rich and colorful, and there are higher requirements for display definition, viewing angle range width and working temperature. The common TFT viewing angle range of 50° on the market and the operating temperature of -20 to +70 °C can no longer meet the needs of users. Therefore, Xin Hongtai Company has launched a series of wide-view TFT display screens, which can reach the viewing angle of 80° or more in both the up, down, left and right directions, and the HD perfect quality display with almost full viewing angle. Most wide viewing angle TFT displays The operating temperature is also increased to -30~+80°C.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Effective size mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3.5''TFT/320*480/Full View/TFT-H035A3HVIST4R50 | TFT LCD | 320x480 |
|
54.76x83.58x2.5 | 3.5 | 3.5 | 48.96x73.44 | Full View | 600cd/m2 | FPC-50PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 3.3v | ST7796S | |
| 3.5 inch TFT horizontal screen︱320*240 resolution︱4:3 wide viewing angle︱TFT-H035A1QVIST6R54 | TFT LCD | 320x240 |
|
76.84x63.84 | 3.5 | 3.5 | 70.08x52.560 | Ful view | 600cd/m2 | FPC-54PIN | RGB | TTL8/24-BIT | -30~85℃ | 3.3v | ST7272A | |
| 4.3 inch TFT LCD screen|480*272 resolution|IPS full view|H043B1WQIST6N40 | TFT | 480x272 |
|
105.5x67.20x3.0 | 4.3 | 4.3 | 95.04x53.86 | Full view | 600cd/m2 | FPC-40PIN | RGB | Anti-static ESD 8KV | -20~70℃ | 3.3v | SC7283 | |
| 1.77inches /128x160 TFT-H017B1CFTST2N20_V0 | TFT LCD | 128x160 |
|
34.0x43.7x2.5 | 1.77 | 1.77 | 35.04x28.032 | 12H | 200cd/m2 | FPC-20PIN | MCU | MCU/8BIT | -20~70℃ | 3.3V | ST7735S | |
| 4.3 inch TFT horizontal screen | 800x480 resolution | IPS full viewing angle | Capacitive touch screen | TFT-H043A10SVIST5C40 | TFT LCD | 800x480 |
|
105.5x67.2x4.55 | 4.3 | 4.3 | 95.04x53.85 | Full view | 1000cd/m2 | FPC | RGB | TTL18bit/24bit | -30~80℃ | 3.3v | ST7262 | |
| 4.0 inch/480*800 resolution/IPS full viewing angle/high brightness/capacitive touch screen/TFT-H040A2WVIIL5C33 | TFT LCD | 480x800 |
|
51.84x86.40 | 4.0 | 4.0 | 51.84x86.4 | Full view | 500cd/m2 | FPC | MIPI | Anti-static ESD 8KV | -20~70℃ | 2.8v | ILI9806E | |
| 1.44 inch/128*128 resolution/serial and parallel compatible/optional touch screen/TFT-H014A1QQTST2N26 | TFT Strip | 128x128 |
|
29.5x36.5x2.55 | 1.44 | 1.44 | 25.498x26.496 | 12OClock（U70/D60/L70/R70） | 500cd/m2 | 26PIN0.5 | MCU | -20~70℃ | 2.8V | ST7735S | ||
| 2.8''TFT240X320 Full View High brightness TFT-H028A1QVIST6N40 | TFT LCD | 240x320 |
|
49.6x69.0x2.4 | 2.8 | 2.8 | 43.20x57.60 | Full View | 600cd/m2 | 40pin | MCU | MCU8/16&SPI 3L/4l | -20~70℃ | 2.8V | ST7789V | |
| 4.3"TFT/480*272 Full View / High brightness /With RTP /TFT-H043A2WQIST5R40 | TFT LCD | 480x272 |
|
105.5x67.2x4.2 | 4.3 | 4.3 | 95.04x53.86 | Full View | 500cd/m2 | 40pin | RGB | With RTP|TTL8/24-BIT | -20~70℃ | 3.3V | SC7283 | |
| 12.3''TFT/1920*720/LVDS/TFT-H123C3RNGD1E0_(1920x720)LVDS | Auto TFT | 1920*720 |
|
313.8x132.2x13.3 | 12.3 | 12.3 | 292.032x109.512 | Full View | 850cd/m2 | 40PIN/IPEX(20455-040E-12) | LVDS | Anti-static ESD 8KV | -30~85℃ | 3.3V |
