With the wide application of human-machine interface, the display content is gradually rich and colorful, and there are higher requirements for display definition, viewing angle range width and working temperature. The common TFT viewing angle range of 50° on the market and the operating temperature of -20 to +70 °C can no longer meet the needs of users. Therefore, Xin Hongtai Company has launched a series of wide-view TFT display screens, which can reach the viewing angle of 80° or more in both the up, down, left and right directions, and the HD perfect quality display with almost full viewing angle. Most wide viewing angle TFT displays The operating temperature is also increased to -30~+80°C.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Effective size mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10.1 inch 1280*800 resolution/IPS full viewing angle LVDS interface/TFT module/sunlight readable/capacitive touch screen/TFT-H101A10WXIFT8C40 | TFT LCD |
|
229.10x148.90x4.35mm | 10.1 | 10.1 | 216.96x135.60 | Full view | 800cd/m2 | 40pin | LVDS | With capacitive touch function | -20~70℃ | 3.3V | EK79202B1 | ||
| 10.1inch 1280x800 IPS LVDS TFT Module Sunlight Readable/TFT-H101A10WXIFTKN40 | TFT LCD | 1280x800 |
|
229.10x148.90x4.35mm | 10.1 | 10.1 | 216.96x135.60mm | Full view | 1000cd/m2 | 40pin | LVDS | Anti-static ESD 8KV | -20~70℃ | 3.3V | EK79202B1 | |
| 7.0 Inch LCD TFT1200x1920 IPS TFT Display HX8279 TFT Module TFT-H070D12ZFIHX2N4 | TFT LCD | 1200x1920 |
|
99.75x161.60x2.20 | 7.0 | 7.0 | 94.50x151.20 | Full view | 350cd/m2 | 40pin | MIPI | Anti-static ESD 8KV | -20~70℃ | 5.5V | HX8279 | |
| i8080 MCU 4.3 Inch TFT 480x272 Sunlight Readable Capacitive TFT Display GT911/TFT-H043A22WQIST8C40 | TFT LCD | 480x272 |
|
105.46x67.11x4.30 | 4.3 | 4.3 | 95.04x53.86 | Full view | 850cd/m2 | 46pin | SPI | Anti-static ESD 8KV | -30~80℃ | 3.3V | GT911 | |
| 4.3 Inch SPI TFT | 480x272 | Sunlight Readable Resistive TFT Display SPI-MCU | TFT-H043A22WQIST8R40 | TFT LCD | 480x272 |
|
105.46x67.11x4.60 | 4.3 | 4.3 | 95.04x53.86 | Full view | 850cd/m2 | 40pin | SPI | Anti-static ESD 8KV | -30~80℃ | 3.3V | T.B.D | |
| 4.3 Inch MCU TFT480x272 Sunlight Readable TFT IPS Display Module/TFT-H043A22WQISTKN40 | TFT LCD | 480x272 |
|
105.46x67.11x3.00 | 4.3 | 4.3 | 95.04x53.86 | Full view | 1000cd/m2 | 40pin | SPI | Anti-static ESD 8KV | -30~80℃ | 3.3V | T.B.D | |
| 2.4 inch TFT/240*320 resolution/SPI interface/full viewing angle/sunlight readable/TFT-H024A16QVIST6N10 | SPI-TFT | 240x320 |
|
42.52x59.61x2.2 | 2.4 | 2.4 | 36.72x48.96 | Full view | 600cd/m2 | 10pin | SPI | Anti-static ESD 8KV | -30~80℃ | 3.3V | ST7789 | |
| 2.0 inch TFT/240*320 resolution/SPI interface/full viewing angle/sunlight readable/TFT-H020A6QVIST6N10 | SPI-TFT | 240x320 |
|
35.7x51.2x2.3 | 2.0 | 2.0 | 30.6x40.8 | Full view | 600cd/m2 | 10pin | SPI | Anti-static ESD 8KV | -30~80℃ | 3.3V | ST7789 | |
| 2.4-inch TFT LCD/handheld collector display /240*320 resolution/industrial grade/with RTP resistor touch /SPI interface /TFT-H024A5QVIST8R18 | SPI-TFT | 240x320 |
|
42.52x59.86x3.40 | 2.4 | 2.4 | 36.72x48.96 | Full view | 800cd/m2 | 18PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 2.8V | ST7789V | |
| 63/5000 2.8-inch TFT color screen /240*320 resolution /SPI interface/full view/ultra-bright 500cd/m2/TFT-H028A16QVIST5N10 | SPI-TFT | 240x320 |
|
50.0x69.20x2.3 | 2.8 | 2.8 | 43.20x57.60 | Full view | 500cd/m2 | 10PIN | SPI | Anti-static ESD 8KV | -30~80℃ | 3.3V | ST7789 |
