With the wide application of human-machine interface, the display content is gradually rich and colorful, and there are higher requirements for display definition, viewing angle range width and working temperature. The common TFT viewing angle range of 50° on the market and the operating temperature of -20 to +70 °C can no longer meet the needs of users. Therefore, Xin Hongtai Company has launched a series of wide-view TFT display screens, which can reach the viewing angle of 80° or more in both the up, down, left and right directions, and the HD perfect quality display with almost full viewing angle. Most wide viewing angle TFT displays The operating temperature is also increased to -30~+80°C.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Effective size mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4.5寸TFT/480*854Resolution/MCU interface/TFT-H045C1FWTNT4N40 | TFT LCD | 480x854 |
|
60.00×109.00×2.25 | 4.5 | 4.5 | 55.44x98.64 | 12H | 400cd/m2 | FPC-40PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 2.8v | NT35510S | |
| 2.4 inch TFT/240*320 resolution/SPI interface/TFT-H024C8QVTST2N18 | TFT LCD | 240x320 |
|
42.72x60.26x2.30 | 2.4 | 2.4 | 36.72x48.96 | 12 o 'clock | 250cd/m2 | FPC-18PIN | SPI | -20~70℃ | 2.8v | ST7789V | ||
| 3.2 inch TFT/240x320 resolution/SPI serial port parallel port/TFT-H032A2QVTST3N40 | TFT LCD | 240x320 |
|
54.0x73.3x2.9 | 3.2 | 3.2 | 47.88x63.84 | 3H | 350cd/m2 | FPC-40PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 2.8V | ST7789V | |
| 2.4 inch TFT/240*320 resolution/MIPI interface/TFT-H024A6QVIFT5C15 | TFT LCD | 240x320 |
|
42.72x60.26 | 2.4 | 2.4 | 36.72x48.96 | 全視角 | 500cd/m2 | FPC-15PIN | MIPI | -20~70℃ | 2.8v | JD9852 | ||
| 1.14 inch bracelet standard screen/135*240 resolution/TFT-H011A1QCIST3N10 | TFT LCD | 135x240 |
|
17.6x31.0x1.65 | 1.14 | 1.14 | 14.86x24.91 | Full View | 350cd/m2 | FPC | SPI | -20~70℃ | 2.8V | ST7789H2 | ||
| 7.0 inch 800x480 high lighting /TFT-H070A5SVTFT8N40 | TFT LCD | 800x480 |
|
164.9x100.0x5.6 | 7.0 | 7.0 | 153.84x85.632 | 6H | 800cd/m2 | FPC-40PIN | RGB | Anti-static ESD 8KV | -20~70℃ | 3.3V | EK9716BD4+EK73002AB2 | |
| 4.0 inch/ 480*800 resolution/ IPS /TFT-H040B5WVIIL4N45 | TFT LCD | 480x800 |
|
57.14x96.85x2.1 | 4.0 | 4.0 | 51.84x86.4 | Full View | 400cd/m2 | FPC-45PIN | RGB | Anti-static ESD 8KV | -20~70℃ | 2.8v | ILI9806E | |
| 2.0 inch TFT/320*240Resolution/RGB/TFT-H020A1LQTIL7N40-V0 | TFT LCD | 320x240 |
|
46.1x40.96x2.53 | 2.0 | 2.0 | 40.8x30.6 | Full view | 700cd/m2 | FPC-40PIN | RGB | Anti-static ESD 8KV | -20~70℃ | 3.3v | ILI9342C | |
| 7.0 inch 1024 * 600 wide perspective/highlighting 7" TFT - H070A2WSIFT8N50 | TFT LCD | 1024x600 |
|
164.9x100.0x5.5 | 7.0 | 7.0 | 154.21x85.92 | Full View | 800cd/m2 | 50PIN | RGB | Anti-static ESD 8KV | -20~70℃ | 3.3V | EK79001+EK73215 | |
| 5.0 inch / 800 * 480 resolution/perspective/highlight/Wide temperature TFT - H050A1SVIST6N40 | TFT LCD | 800x480 |
|
120.7x75.8x3.0 | 5.0 | 5.0 | 108.0x64.8 | Full View | 600cd/m2 | 40pin | RGB | Wide temperature | -30~80℃ | 3.3V | ST7262 |
