Plated COG LCD Module

The COG liquid crystal module is a component that assembles a COG liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the COG liquid crystal module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.

Screening results
Checklist Model Product type Show contents Product map Outline size
(mm)
Horizon
(mm)
Display size
mm/inch
Point spacing
mm
Visual angle Brightness Pin Interface Instructions Working temperature Voltage Driver chip model
HTM12864-123-25W-A3S-V01 LCM 128x64 71.0x62.0x7.8 65.5x38.0 60.77x32.93 6H WHITE 12PIN SPI 可帶中文字庫 -20~80℃ 3.3V ST7567
HTM-COG12864C01A-SPI LCM 128x64 52.0x44.2x5.2 36.0x23.5 33.25x20.45 6H WHITE 12PIN SPI -20~70℃ 3.3V ST7567
128*64 LCM Graphic/HTM12864-109 LCM 128x64 93.0x70.0x13.5 65.5x38.0 60.77x32.93 0.51x0.48 6H 白色 SPI -20~70℃ 3.3v ST7565R
128x64 LCM Graphic/HTM12864-108 LCM 128x64 93.0x70.0x13.5 72.0x39.5 66.52x33.24 0.52x0.52 6H 白光 20PIN SPI Anti-static ESD 8KV -20~70℃ 3.3v ST7565R
128x64 LCM Graphic/HTM12864-7 Graphic LCM 128x64 95.0x56.7x13.5 65.6x38 60.775x32.935 0.475x0.515 6H WHITE 9PIN SPI Anti-static ESD 8KV -20~70℃ 3.3V ST7565R
128x64 LCM Graphic/HTM12864C02 Graphic LCM 128x64 40.6x32.2x11.0 37.0x23.3 33.26x20.48 0.26x0.32 6H WHITE FFC-18PIN MCU MCU/8BIT -20~70℃ 3.3V ST7565R
128x64 LCM Graphic/HTM12864-27 Graphic LCM 128x64 93.0x70.0x13.5 65.5x38.0 60.775x32.935 0.475x0.515 6H WHITE 20PIN SPI -20~70℃ 5.0v ST7565R
128x48 LCM Graphic/HTM12848A Graphic LCM 128x48 100.3x45.0x12.5 75.8x29.0 66.52x24.92 0.52x0.52 6H WHITE 8PIN SPI Anti-static ESD 8KV -20~80℃ 3.3v ST7565R
160x160 LCM Graphic/HTM160160C Graphic LCM 160x160 82.4x66.0x9.5 60.0x60.0 54.38x54.38 0.34x0.34 6H WHITE FFC-18PIN MCU MCU/8bit -20~70℃ 3.3v UC1698
128x64 LCM Graphic/HTM12864-23 Graphic LCM 128x64 54.6x50.0x9.1 45.2x27.0 40.93x24.29 0.38x0.32 6H YG 16PIN MCU MCU/8bit or SPI -20~70℃ 3.3v
